LiTime 12V 100Ah Smart ComFlex battery with Bluetooth & Victron communication
12.8 V 100 Ah LiFePO4 battery in a Group 31 case. Different from conventional models with CAN and RS485 ports: the battery is connected to the Victron system directly, without a shunt, and the charge, current and temperature are visible in VictronConnect and on the VRM. Read more →
10%
Discount coupon from the manufacturer
Works on the "Buy from manufacturer" button. This coupon does not apply to AliExpress.
Enter the code in the cart on the manufacturer's website - the discount will be applied to the order.
- 5-year warranty. Long-lasting protection, worry-free use.
- Without VAT Additional value added tax is not charged.
- Free delivery Fast local delivery
12.8 V 100 Ah LiFePO4 battery in a Group 31 case. Different from conventional models with CAN and RS485 ports: the battery is connected to the Victron system directly, without a shunt, and the charge, current and temperature are visible in VictronConnect and on the VRM.
Bluetooth 5.0 works within a radius of up to 10 meters, the LiTime application shows more than 25 indicators. BMS firmware is updated via OTA, so new protocols are added remotely.
BMS T5.0 holds 100 A continuous charge and 500 A peak per second. Useful energy 1280 Wh, resource over 4000 cycles at 100% DOD. More than 20 protection functions, after an overload, the power is restored in 30 seconds.
In the communication mode, connect up to 16 batteries in parallel and control them with one button. A 4P4S scheme is available without communication.
Dimensions 330 × 172 × 216 mm, weight 9.8 kg, housing IP65. Charge is blocked below 0 °C, discharge below -20 °C, charge recovery from 5 °C.
| Producer | LiTime |
| Article | L12V100-100-COM-BT-4-A100-DE |
| Type | LiFePO4 |
| Nominal voltage | 12.8 V |
| Capacity | 100 A h |
| Energy | 1280 Wh |
| Type size | Group 31 |
| Maximum charge current | 100 A |
| Maximum discharge current | 100 A |
| Bluetooth | Yes, 5.0, radius up to 10 m |
| Ports | CAN, RS485, Bluetooth 5.0 |
| Protection against low temperatures | Yes, the charge is blocked below 0 °C, the discharge below -20 °C |
| Protection class | IP65 |
| Resource | 4000 cycles at 100% DOD, 6000 at 80%, 15000 at 60% |
| Protection | More than 20 BMS functions, automatic recovery in 30 seconds |
| Assembly scheme | Up to 16 batteries in parallel in communication mode; 4P4S without communication |
| Compatibility | Victron VE.Can, VRM, VictronConnect, RV-C, NMEA 2000 |
| Dimensions (L×W×H) | 330 × 172 × 216 mm |
| Weight | 9.8 kg |
| Guarantee | 5 years |
| Certificates | CE, FCC, RoHS, UKCA |
| Working temperature | From -20 to 60 °C |
